Certifications
- CE Certified
- IP65 Waterproof Protection
Key Product Specifications
- Material: Aluminum + PC
- CRI: RA ＞ 75
- Protection Grade: IP65
- Service Life: 50,000 hours
- CCT Options: 3000K – 6500K
- Ambient Temperature: -40°C to +50°C
- Beam Angle: 150°
Specification Table
| Model |
Rated Voltage (V) |
Operating Current (A) |
Power (W) |
Light Source |
Power Output Current (mA) |
Luminous Flux (lm) |
Packing Size (mm) |
| YMLED-6141 (16) |
120–277 |
0.60 |
30 |
SMD |
700 |
3450 |
415 × 415 × 530 |
| YMLED-6141 (24) |
120–277 |
1.05 |
55 |
SMD |
700 |
6325 |
415 × 415 × 530 |
Lumen Diagram
Available lighting distribution types include Type 1, Type 2, and Type 3, suitable for different outdoor illumination applications.
Product Dimensions
Overall Diameter: Ø400 mm
Total Height: 490 mm
Mounting Pipe Diameter: 80 mm
Standards Complied
- EN IEC 55015:2019 + A11:2020
- EN IEC 61547:2023
- EN IEC 61000-3-2:2019
- EN 61000-3-3:2013 + A1:2019
- EN 60598-2-3:2003 + A1:2011
- EN 60598-1:2021
- EN 62493:2015
Application Scenarios
- Municipal parks and outdoor recreational areas
- Residential gardens and landscape lighting
- Government and institutional outdoor spaces
- Pathways, sidewalks, and pedestrian zones
- Campus and school lighting
- Commercial building exteriors
Product Advantages
- Highly durable housing designed for outdoor environments
- Wide working temperature range from -40°C to +50°C
- Long lifespan reduces replacement and maintenance cost
- Uniform light distribution with 150° beam angle
- Waterproof IP65 rating ensures resilience in rain and humidity
- Available in 30W and 55W to meet different brightness needs
FAQ
Q1: Can the LED Garden Light withstand heavy rain?
Yes. With an IP65 rating, it is fully protected against dust and water jets, suitable for all-weather outdoor use.
Q2: Is installation complicated?
No. The lamp is designed to fit standard outdoor garden poles with an 80 mm mounting connection.
Q3: What is the typical lifespan of this garden light?
It offers up to 50,000 hours of service life under normal outdoor operation.
Q4: What color temperatures are available?
The product supports 3000K (warm), 4000K (neutral), 5000K (cool), and 6500K (daylight).
